WNRTJ Flange

• Design:The RTJ (Ring Type Joint) flange is a type of flange designed for high-pressure and high-temperature applications. It features a groove or recess into which a metal ring gasket is placed. The ring joint gasket, which has a circular cross-section, is compressed between the flanges to create a reliable, leak-tight seal.


• Applications: WNRTJ Flanges are commonly used in industries requiring high-pressure and high-temperature service, such as in oil and gas, petrochemical, chemical processing, and power generation. They are particularly useful in critical applications where standard gaskets might not provide adequate sealing performance.


• Installation: The WNRTJ Flange is installed by placing the metal ring gasket into the machined groove of the flange. When the flange is bolted to a mating flange, the gasket is compressed between the flanges to ensure a tight, secure seal.

Chemical and Mechanical Properties Table

Material	Grade	Chemical Composition (wt%)	Yield Strength (MPa)	Tensile Strength (MPa)	Elongation (%)
Carbon Steel	ASTM A105	C: 0.35 max, Mn: 0.60-0.90, P: 0.035 max, S: 0.035 max	205 - 250	420 - 550	20
Stainless Steel	ASTM A182 F304	C: 0.08 max, Cr: 18.0-20.0, Ni: 8.0-10.5	205 - 310	510 - 720	40
Stainless Steel	ASTM A182 F316	C: 0.08 max, Cr: 16.0-18.0, Ni: 10.0-14.0, Mo: 2.0-3.0	205 - 310	510 - 720	40
Alloy Steel	ASTM A234 WP22	C: 0.12-0.20, Cr: 1.0-1.5, Mo: 0.4-0.6	205 - 275	485 - 620	20
High-Temperature Alloy	ASTM A182 F91	C: 0.05-0.15, Cr: 8.0-9.5, Mo: 0.85-1.05	415 - 485	620 - 825	20

Notes:

• Chemical Composition: Indicates the elements present in the material, such as chromium and nickel, which contribute to properties like corrosion resistance.


• Yield Strength: The stress at which the material begins to deform permanently.


• Tensile Strength: The maximum stress the material can withstand while being stretched or pulled before breaking.


• Elongation: Represents the ductility of the material, indicating how much it can stretch before breaking.
